Low Table Model Automatic Carton Strapping Machine
The Automatic Carton Strapping Machine is designed for fully automatic strapping. It features a powered roller table that can strap objects of different sizes and shapes. The machine can be integrated with powered conveyor or assembly lines for completely unmanned operation. The size and weight of objects to be strapped can be customized according to customer requirements. The drive unit is equipped with a dust cover and a special design that allows for quiet, powerful operation. It also includes an automatic shutdown function to save energy. Strapping methods include manual parallel one-to-multiple straps and photoelectric control two straps according to customer requirements.
Specification:
| Packaging Speed | 2.5seconds/time |
| Table Height | 450mm (It can be highly customized according to user needs.) |
| Strapping Method | Parallel operation, 1 to multiple times, with options for automatic, manual, continuous firing, ball switch, and foot switch. |
| Applicable Strapping Tape | thickness(0.55～1.2)mm*width(9～15)mm |
| Power Supply | 380V,50/60Hz 750W,5A |
| Machine Weight | 330kg(Gross weight)/250kg(net weight) |
| Frame Dimensions | W(1070)xH(668)mmexternalW(800)xH(600)mm, Custom Accept |
